BTT-I06-1 – Wall Insertion Temperature Sensor for Practical Applications

Posted on: 22/08/2025

In HVAC and BMS systems, monitoring the temperature of air ducts or partition walls plays a crucial role in ensuring stable operation and energy efficiency.

The BTT-I06-1 – a wall insertion temperature sensor from Dwyer Instruments (USA) – is designed to measure air or fluid temperature indirectly through a wall, enabling accurate data collection without direct contact with the measured environment. This makes it ideal for a wide range of real-world applications.

1. Product Overview

BTT-I06-1  belongs to the group of Wall Insertion Temperature Sensors. It is mounted directly into a wall or duct surface, with the probe extending through to measure temperature on the other side. The sensor transmits signals back to a controller or BMS.

Key Features:

  • Compact design, easy installation on various surfaces

  • Stainless steel probe, corrosion-resistant and heat-tolerant

  • Uses RTD PT100/1000 or Thermistor sensor for high accuracy

2. Key Technical Specifications

  • Sensor Type: RTD PT100/1000 or Thermistor (optional)

  • Temperature Range: -50 to 150°C (depending on version)

  • Probe Material: SUS304/SUS316 stainless steel

  • Probe Length: 150mm (customizable)

  • Signal Output: 4–20mA, 0–10V, or resistance signal

  • Protection Rating: IP65 – dust-tight and water-resistant

Thanks to its flexible configuration, the BTT-I06-1 can easily meet various technical requirements in different projects.

3. Advantages of Using BTT-I06-1

  • Easy Installation: Just drill and fix the sensor in plac

  • High Accuracy: Equipped with high-quality Dwyer sensing elements

  • Exceptional Durability: Corrosion-resistant, impact-resistant casing and probe

  • Easy Maintenance: Quick removal for inspection or replacement

  • BMS/HVAC Compatibility: Supports common industry-standard signal outputs

4. Real-World Applications

The BTT-I06-1 is widely used in:

  • Monitoring temperature in air ducts of central air conditioning systems

  • Supervising cold storage or clean room temperatures via partition walls

  • Tracking production area temperatures in industrial facilities

  • Smart agriculture: greenhouses, agricultural storage rooms

Thanks to its through-wall measurement capability, this sensor is particularly useful in environments that need to be isolated from the measurement zone.

5. DLK – Authorized Distributor

When purchasing the BTT-I06-1 from DLK, you receive:

  • Genuine Dwyer products with full CO/CQ documentation

  • In-depth technical consultation from HVAC & BMS experts

  • Customizable specifications to suit project requirements

  • Fast warranty service and local stock availability

With its durable wall-insertion design, accurate sensing, and versatile application, the BTT-I06-1 is an ideal choice for modern HVAC, BMS, and industrial systems
