Differential Pressure transmitter Dwyer Series DM
Giá bán:
Contact
Product information
The Dwyer Series DM DigiMag® Differential Pressure Transmitter senses the pressure of air and compatible gases and sends a standard 4-20 mA output signal with a large LCD display.
✔ Digital Display: 4-digit LCD provides easy-to-read local indication of differential pressure
✔ Flexible Setup: Programmable push-buttons for selecting units, response time, and Zero/Span calibration
✔ Retrofit Design: Housing fits the same diameter cutout as a standard Magnehelic® gauge
✔ Output Signal: 2-wire 4-20 mA loop-powered output with digital filter for stable readings
✔ Rugged Construction: Durable polycarbonate housing, NEMA 4X (IP66) rated when properly installed
Tags:
-
🚚 Imported by bởi DLK TRADING SERVICE COMPANY LIMITED.
-
✅ Quality : Hàng mới 100%, đảm bảo chính hãng, đầy đủ hồ sơ nhập khẩu.
-
🛠️ Guarantee : 12 tháng, (tùy chọn 36 tháng).
-
📞 Phone : 0937972339
Cam kết sản phẩm
- Technical characteristics
- Name of the product
- Standard technical document
Detailed Specifications
|
Brand |
DWYER (USA) |
|
Service |
Air and non-combustible, compatible gases |
|
Accuracy |
±1% FSR (±2% on 0.25 in w.c. range) |
|
Pressure Limits |
2 psi (13.79 kPa) maximum continuous |
|
Temperature Limits |
-4 to 158°F (-20 to 70°C) |
|
Output Signal |
4-20 mA (2-wire loop) |
|
Enclosure Rating |
NEMA 4X (IP66) front face |
Model CHART DigiMag® Series DM
|
Model |
Range (in w.c.) |
Range (Pa) |
Range (mm w.c.) |
|
DM-001 |
0 to .100 |
24.9 |
2.54 |
|
DM-002 |
0 to .250 |
62.2 |
6.35 |
|
DM-003 |
0 to .500 |
124.3 |
12.7 |
|
DM-004 |
0 to 1.000 |
249 |
25.4 |
|
DM-005 |
0 to 2.00 |
497 |
50.8 |
|
DM-007 |
0 to 3.00 |
746 |
76.2 |
|
DM-008 |
0 to 5.00 |
1243 |
127.0 |
|
DM-019 |
-0.05 - 0 - 0.20 |
-12.45 to 49.81 |
-1.269 to 5.079 |
|
DM-201 |
±0.1 |
-24.9 to 24.9 |
-2.53 to 2.53 |
|
DM-202 |
0 to ±.250 |
0 to ±62.2 |
0 to ±6.35 |
|
DM-203 |
0 to ±.500 |
0 to ±124.3 |
0 to ±12.70 |
|
DM-052 |
0 to .120 |
30 |
3.05 |
|
DM-053 |
0 to .240 |
60 |
6.11 |
|
DM-056 |
0 to 1 |
250 |
25.49 |
|
DM-059 |
0 to 5 |
1250 |
127.46 |
|
DM-252 |
±.120 |
±30 |
-3.05 to 3.05 |
|
DM-253 |
±.240 |
±60 |
-6.11 to 6.11 |
|
DM-256 |
-1 to 1 |
±250 |
-25.49 to 25.49 |
|
DM-259 |
-5 to 5 |
±1250 |
-127.46 to 127.46 |
|
DM-082 |
0 to 0.23 |
58.83 |
6 |
|
DM-282 |
-0.23 to 0.23 |
-58.83 to 58.83 |
±6 |
